| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 987691 | DOOR – evaporator (bolt-on door) | 1 |
| 1 | 511460TKA | SCREW – door (M8, TIR seal) | 4 |
| 1 | 511430 | FLATWASHER (M8) | 4 |
| 1 | 559541 | WASHER (M8, nylon) | 4 |
| 1 | 511459 | SCREW – door (M6, TIR seal) | 4 |
| 1 | 511464 | FLATWASHER (M6) | 4 |
| 1 | 559054 | WASHER (M6, nylon) | 4 |
| 2 | 333969 | GASKET – evaporator door | 1 |
| 3 | 918728 | COVER (instead of thermometer) | 1 |
| 3 | 511467 | SCREW – cover | 3 |
| 3 | 511444 | FLATWASHER | 3 |
| 4 | 985925 | GRILLE – condenser (see 189C4) | 1 |
| 4 | 989602 | GRILLE – condenser w/ micro channel coil | 1 |
| 4 | 333043 | GASKET – rubber extrusion | 1 |
| 4 | 511445 | SCREW – grille | 4 |
| 4 | 511464 | FLATWASHER | 4 |
| 4 | 559054 | WASHER (nylon) | 4 |
| 5 | 918475 | NAMEPLATE – TK | 1 |
| 6 | 918474 | PLATE – guard | 1 |
| 6 | 557341 | SCREW – plate | 3 |
| 6 | 511464 | FLATWASHER 6 | 6 |
| 6 | 559054 | WASHER – insulation | 6 |
| 7 | 986560 | PLATE – cable storage (units w/o water cooled cond) | 1 |
| 7 | 986236 | PLATE – cable storage (units w/ water cooled cond) | 1 |
| 7 | 511425 | NUT | 2 |
| 7 | 559054 | WASHER (nylon) | 4 |
| 7 | 511464 | FLATWASHER | 4 |
| 8 | 918108 | BRACKET – frame | 1 |
| 8 | 511442 | SCREW – bracket | 5 |
| 8 | 511425 | NUT | 3 |
| 8 | 559054 | WASHER (nylon) | 5 |
| 8 | 511464 | FLATWASHER | 5 |
| 9 | 920891 | BRACKET – safety hook | 1 |
| 9 | 511443 | SCREW – bracket | 4 |
| 9 | 511430 | FLATWASHER | 4 |
| 9 | 559541 | WASHER (nylon) | 4 |
| 10 | 332983 | GASKET – unit | 1 |
| 11 | NSS | FRAME – condenser | 1 |
| 12 | 919754 | * POCKET – sensor | 2 |
| 13 | 334829 | GASKET – door | 4 |
| 14 | 612271 | TUBE & VALVE – vacuum | 1 |
| 15 | 919949TKA | PORT – injection (optional) | 2 |
| 15 | 511448 | RIVET – port | 4 |
| 16 | 919950TKA | HOUSING – relief valve | 1 |
| 16 | 511448 | RIVET – housing | 1 |
| 17 | 919951TKA | VALVE – pressure relief | 1 |
| 18 | 615619 | VALVE – vacuum | 1 |
| 19 | 986518 | DOOR – evaporator (bolt-on door) | 1 |
| 20 | 5091654 | * HINGE | 2 |
| 21 | 918256TKA | * PIN – hinge | 2 |
| 22 | 919040TKA | * KNOB | 2 |
| 23 | 919041TKA | * LATCH – door | 2 |
| 24 | 918199 | * SPRING | 2 |
| 25 | 511459 | * SCREW – door | 2 |
| 26 | 512078 | * NUT | 2 |
| 27 | 510619 | * WASHER | 2 |
| 28 | 918134 | * INSULATOR – latch | 2 |
| 29 | 553101 | * RIVET | 4 |
235E0
235G1
226E2
247C9
